Tricolor USB alert

Last update: Thu Jun 5 22:25:41 2025

Software

Firmware

See my dedicated page about V-USB: USB without Arduino
Basic code explanation for this project is the firmware source of the chapter Keyboard : Receiving data from host as a HID (no driver). I will list here only relevant details added to the basic design.

Windows software

Who said C# programming ? http://www.codeproject.com/Tips/530836/Csharp-USB-HID-Interface

Hardware

Wiring: http://vusb.wikidot.com/hardware using the 3.6v zener diode design, so it allows the micro controller to run at 5V.
On the diagram the pins are:

Vcc (5v)
D-
D+
GND

IMPORTANT: I failed many time at this design (at least twice) before understanding what I did wrong. So follow these rules:

USB data is 3.3v but as stated in the V-USB wiki use 3.6v zener diodes (3.3v is doomed to fail)
If you use the sample codes from V-USB be careful to use the same pins as them, especially for D- which uses an interrupt. If you change the pin, mind changing the interrupt that is associated. All is done in the usbconfig.h file, read it carefully, it will save you hours of problem solving.
Some people pullup the D+ with a 1 MOhm resistor, I don't and it still work so ignore this

MCU : Attiny2313 running at 12MHz (ext crystal)
Board: Rapide2313 that I made and had still lying around. Not a great success this board in terms of silking, plus a few minor issues, but it works.

Basic diagram: signal leds will be replace by big 1cm diameter leds and driven by a transistor each, that will be the only change (see USB without Arduino for details)

Documentation

All the USB documentation http://www.usb.org/developers/hidpage/

usb without arduino

Links to tutorials http://www.avrfreaks.net/forum/tut-hard-soft-c-usb-tutorial-v-usb-attiny
